PVC geodesic dome tent

General Details

Details:

PVC geodesic dome tent is our most popular tents. Over the years, geodesic dome tents have been popular in the domestic market for many types of projects such as large-scale exhibitions, music festivals, parties and other activities. Therefore, Qiangyu Tent takes high-tech on R&D innovation and optimization of each geodesic dome tent.

PVC geodesic dome tent from Qiangyu is available on span width 3m to 50m, which can be applied on the different scale of activities. Besides, Qiangyu can offer different design for tent rooftop. Nowadays, Qiangyu Tent has designed 5 membrane options for our clients:

Transparent front: white, opaque PVC fabric with detachable, exchangeable clear, transparent front part, our most versatile solution.

Blackout: white, opaque PVC fabric with detachable, exchangeable white, opaque front part, ideal for darkening out the interior.

Transparent membrane: Completely transparent PVC cover, ideal for night events, giving you the possibility to create magical light effects.

Branded membrane: Fully color printed fabric or printed detachable front part, ideal to put your brand’s message across.

Open dome: a unique 2-in-1 solution that combines the classic geodesic dome structure with a completely innovative mobile stage system.

Opaque PVC fabric can be replaced with non-opaque, single layer cover, which is perfect to create lighting effects visible from outdoor.

PVC geodesic dome tent is made of high-strength Q235 steel pipe, with a solid design, removable and reusable. The appearance is stylish but not obvious, giving a sense of understated simplicity. Tent structure is anti-UV, rot proof, moldy proof, anti-aging, wind loading, waterproof and flame-retardant. They all have relevant certificates. Thanks for foldable PVC fabric and disassemble framework, the volume is small and easy to transport and store.


Features:


◆ The dome tent is easy and fast to assemble and dismantle. We will offer the installation manual and vedio

 No pole inside the dome tent,100% available interior space

 The frame of the tent is rustless and eco-friendly

 Full line access ories available. You can chose the accessories for the tent accord to your requirement

◆ You can customize any size of the tent you need




Structure
Size

Diameter

Ceiling Height

Floor Area

Volume

Struts Details

3m

2.3m

7.1m²

12.7m³

20mm

4m

2.89m

12.6m²

28m³

20mm

5m

2.93m

19.6m²

41m³

20mm

6m

3.52m

28.3m²

70m³

20mm

7m

4.1m

38.5m²

110m³

26mm

8m

4m

50.2m²

134m³

26mm

9m

4.5m

63.6m²

191m³

26mm

10m

5m

78.5m²

262m³

26mm

11m

5.5m

95m²

348m³

26mm

12m

6m

113m²

452m³

33mm

13m

5.82m

132.7m²

545m³

33mm

14m

6.27m

153.9m²

685m³

33mm

15m

6.72m

176.6m²

845m³

33mm

16m

7.16m

201m²

1030m³

33mm

17m

8.5m

226.9m²

1285m³

33mm

18m

9m

254.3m²

1525m³

33mm

19m

9.5m

283.4m²

1795m³

33mm

20m

10m

314m²

2090m³

38mm

21m

10.5m

346.2m²

2420m³

38mm

22m

11m

379.9m²

2785m³

38mm

23m

11.5m

415.3m²

3180m³

38mm

24m

12m

452.2m²

3615m³

38mm

25m

12.5m

490.6m²

4090m³

48mm

30m

13m

706.5m²

5744m³

48mm

35m

14m

961m²

8170m³

48mm

40m

15m

1256m²

11191m³

51mm

45m

18m

1589.6m²

17367m³

48mm

50m

20m

1962.5m²

23823m³

48mm


Accessories
Application
